Spesifikasi:
| Pixel Pitch | 10mm |
| Pixel Density | 10000dots/㎡ |
| Module Resolution | (W)16dots X (H)16dots |
| Module size | (W)160mm X (H)160mm |
| Weight of Module | 520g |
| Scanning Mode | 1/4 |
| Work Voltage | DC5V±10% |
| Max Current | 3.2A |
| Max Power Consumption | 17W |
| Signal interface | HUB75(IDC16) |
| Brightness | 7500cd/㎡ |
| Color Temperature | 9500K |
| Viewing Angle | 110/55 |
| Best Viewing Distance | ≥10m |
| Brightness/Chroma adjust | Support |
| Refresh rate | ≥1920Hz |
| Max Power Consumption/m² | 550W/m² |
| Life Span | 100,000 H |
| Operating temperature | -20 ℃ to 50 ℃ |
| Operating Humidity | 10%-90%RH |
| Stock temperature | -30 ℃ to 80 ℃ |
