Spesifikasi:
| Pixel Pitch | 16mm |
| Pixel Density | 3906dots/㎡ |
| Module Resolution | (W)16dots X (H)16dots |
| Module size | (W)256mm X (H)256mm X (D)23mm |
| Weight of Module | 550g |
| Scanning Mode | Static Current |
| Work Voltage | DC5V±10% |
| Max Current | 10A |
| Max Power Consumption | 50W |
| Power interface | VH4 |
| Signal interface | HUB75(IDC16) |
| Brightness | ≥6000cd/㎡ |
| Color Temperature | 9500±500K |
| Viewing Angle | ≦140° |
| Best Viewing Distance | ≥16m |
| Grayscale | 14bits |
| Brightness/Chroma adjust | Support |
| Refresh rate | ≥3840Hz |
| control load | (W)192dots, (H)192dots |
| Brightness adjust | 0 to 255 adjustable |
| Life Span | 50,000 H |
| Operating temperature | -20 ℃ to 60 ℃ |
| Operating Humidity | 10%-80%RH |
| Stock temperature | -40 ℃ to 80 ℃ |
