Spesifikasi:
| Pixel Pitch | 2.5mm |
| Pixel Density | 160000dots/㎡ |
| Module Resolution | (W)64dots X (H)64dots |
| Module size | (W)160mm X (H)160mm X (D) 12mm |
| Weight of Module | 230g |
| Scanning Mode | 1/32 |
| Work Voltage | DC5V±10% |
| Max Current | 4A |
| Max Power Consumption | 20W |
| Power interface | VH4 |
| Signal interface | HUB75E (IDC16) |
| Brightness | ≥1000cd/㎡ |
| Color Temperature | 9000±500K |
| Viewing Angle | ≦140° |
| Best Viewing Distance | ≥2.5m |
| Grayscale | 14bit |
| Brightness/Chroma adjust | Support |
| Refresh rate | ≥1920Hz |
| control load | (W)128dots (H)256dots |
| Brightness adjust | 0 to 255 |
| Life Span | 50,000 H |
| Operating temperature | -10 ℃ to 50 ℃ |
| Operating Humidity | 10%-9%RH |
| Stock temperature | -40℃ to 80 ℃ |
