Spesiifikasi:
| Pixel Pitch | 4mm |
| Pixel Resolution | 62500dots/㎡ |
| Module Resolution | (W)64dots X(H)32dots |
| Module Size | (W)256*(H)128*(D)15.2mm |
| Module Weight | 320g |
| Scan Mode | 1/16 |
| Operation Voltage | DC5V±10% |
| Max Module Current | 6A |
| Max Power Consumptio | 30W |
| Power Interface | VH4 |
| Signal Interface | HUB75(IDC16) |
| Max Brightness | ≥4000cd/㎡ |
| Color Temperature | 9500K |
| Viewing Angle | ≦140° |
| Best Viewing Distance | ≥4m |
| Refresh rate | ≥1920Hz |
| Brightness Adjust Rang | 0 to 255 adjustable |
| Life spam | 50,000 H |
| Operation temperature | -10 ℃ to 50 ℃ |
| Operation humidity | 10%-80%RH |
| Stock temperature | -30 ℃ to 80 ℃ |
