Spesifikasi:
| Pixel Pitch | 6mm |
| Pixel Density | 27777dots/㎡ |
| Module Resolution | (W)32dots X (H)32dots |
| Module size | (W)192mm X (H)192mm X (D)15mm |
| Weight of Module | 370g |
| Scanning Mode | 1/16 |
| Work Voltage | DC5V±10% |
| Max Current | 2.5A |
| Max Power Consumption | 13W |
| Power interface | VH4 |
| Signal interface | HUB75D(IDC16) |
| Brightness | ≥1100cd/㎡ |
| Color Temperature | 9000±500K |
| Viewing Angle | ≦140° |
| Best Viewing Distance | ≥6m |
| Grayscale | 14bit |
| Brightness/Chroma adjus | Support |
| Refresh rate | ≥1920Hz |
| control load | (W)128dots (H)256dots |
| Refresh rate | 0 to 255 |
| Life Span | 50,000 H |
| Operating temperature | -20 ℃ to 60 ℃ |
| Operating Humidity | 10%-90%RH |
| Stock temperature | -40 ℃ to 80 ℃ |
