Spesifikasi:
| Pixel Pitch | 8mm |
| Pixel Density | 15625dots/㎡ |
| Module Resolution | (W)32dots X (H)16dots |
| Module size | (W)256mm X (H)128mm X (D) 23mm |
| Weight of Module | 290g |
| Scanning Mode | 1/4 |
| Work Voltage | DC5V±10% |
| Max Current | 5A |
| Max Power Consumption | 25W |
| Power interface | VH4 |
| Signal interface | HUB75(IDC16) |
| Brightness | ≥5000cd/㎡ |
| Color Coordinat | x=0.27；y=0.27 |
| Color Temperature | 9500K |
| Viewing Angle | ≦140° |
| Best Viewing Distance | ≥8m |
| Working clock | 15.6M Hz |
| Grayscale | 14bits |
| Brightness/Chroma adjust | Support |
| Refresh rate | ≥960Hz |
| control load | (W)192dots (H)192dots |
| Brightness adjust | 0 to 255 |
| Life Span | 50,000 H |
| Operating temperature | -10 ℃ to 50 ℃ |
| Operating Humidity | 10%-80%RH |
| Stock temperature | -30 ℃ to 80 ℃ |
