Spesifikasi:
| Pixel Pitch | 8mm |
| Pixel Density | 15625dots/㎡ |
| Module Resolution | (W)40dots X (H)20dots |
| Module size | (W)320mm X (H)160mm |
| Weight of Module | 490g |
| Scanning Mode | 1/5 |
| Work Voltage | DC5V±10% |
| Max Current | 6.5A |
| Max Power Consumption | 32.5W |
| Signal interface | HUB75(IDC16) |
| Brightness | 5000cd/㎡ |
| Color Temperature | 9500K±500 |
| Viewing Angle | 140/140 |
| Best Viewing Distance | ≥8m |
| Brightness/Chroma adjust | Support |
| Refresh rate | ≥960Hz |
| control load | (W)160dots (H)240dots |
| Life Span | 50,000 H |
| Operating temperature | -20 ℃ to 60 ℃ |
| Operating Humidity | 10%-90%RH |
| Stock temperature | -40 ℃ to 80 ℃ |
